Self-adhesive Membrane Pads (adhesiveVENTpads)
Our "Firewall" to protect your products
Your contact person
Kevin Eckert
Head of FLUXX
Packaging & Industrial
Our adhesiveVENTpads are Membrane Discs equipped with an adhesive ring in various sizes with hydrophobic and oleophobic properties. They are supplied on rolls and are all PFOA/PFCA-free & PFAS-free upon request, of course.
Below you will find the most common membrane variants, further information on specifications and conformity, your product benefits and a selection of application examples. Read more >
Specifications & conformities
| Chemical restistance: | Go to > |
|---|---|
| Temperature resistance: | PET with modified adhesive up to 110 °C PET, PET-non-woven-supported with modified adhesive up to 110 °C These information refer to the respective materials. The functions must be approved for each application itself. |
| Sealing compatibility: | Go to > |
| IP-protection class suitability: | Yes |
All product data given on this website represent typical values.
Benefits
- Available in several standard sizes
- Safe pressure compensation, steady airflow and continuous venting
- Reliable protection against environmental influences such as foreign particles, water, and other liquids.
- Easy product integration (also in existing components)
- Self-adhesive membrane pads can be installed either inside or outside the component and have minimal space requirements
- Can be applied manually, semi-automatically, or fully automatically
- Excellent adhesion on smooth surfaces – especially to plastic, aluminum, and steel
- Individually customizable (e.g. formats and adhesive types)
- Narrow tolerances of the membrane parameters
- Water and oil repellent surface (hydrophobic/oleophobic)
- Suitable for IP protection classes
- PFOA/PFCA-free & PFAS-free upon request (confirmed by accredited test laboratories)
- Production under clean room conditions in accordance with ISO class 8
- Certified according to DIN EN ISO 9001 & 13485
Product found? Order now >
Your product not yet included? Customization options >
Your contact person
Kevin Eckert
Head of FLUXX
Packaging & Industrial
adhesiveVENTpads Standard product portfolio
Our hydrophobic and oleophobic membrane adhesive pads (adhesiveVENTpads) are available in a variety of standard sizes, and upon request, customized for you in different measurements, pore sizes, and additionally with fleece reinforcement.
Show products: Self-adhesive Membrane Pads
adhesiveVENTpad
Ø 5.0 / 2.0 mm
0.4 µm PET
Item Number: 090065
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 0.4 µm
Backing: None
Membrane thickness: 36 µm
Filter area: 0.03 cm2
Air flow rate: 7.0 L /(min cm2 bar)
WEP: 1.8 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 7,000 Pads
In stock
adhesiveVENTpad
Ø 7.0 / 3.0 mm
0.4 µm PET
Item Number: 090067
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 0.4 µm
Backing: None
Membrane thickness: 36 µm
Filter area: 0.07 cm2
Air flow rate: 7.0 L /(min cm2 bar)
WEP: 1.8 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 5,000 Pads
adhesiveVENTpad
Ø 7.5 / 3.0 mm
1.0 µm PET
Item Number: 090056
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 1.0 µm
Backing: None
Membrane thickness: 35 µm
Filter area: 0.07 cm2
Air flow rate: 20 L /(min cm2 bar)
WEP: 0.6 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 5,000 Pads
Upon request
adhesiveVENTpad
Ø 8.0 / 4.0 mm
0.4 µm PET
Item Number: 090071
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 0.4 µm
Backing: None
Membrane thickness: 36 µm
Filter area: 0.13 cm2
Air flow rate: 7.0 L /(min cm2 bar)
WEP: 1.8 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 5,000 Pads
adhesiveVENTpad
Ø 8.0 / 4.0 mm
1.0 µm PET
Item Number: 090020
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 1.0 µm
Backing: None
Membrane thickness: 35 µm
Filter area: 0.13 cm2
Air flow rate: 20 L /(min cm2 bar)
WEP: 0.6 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 5,000 Pads
adhesiveVENTpad
Ø 10.0 / 5.5 mm
0.4 µm PET
Item Number: 090068
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 0.4 µm
Backing: None
Membrane thickness: 36 µm
Filter area: 0.24 cm2
Air flow rate: 7.0 L /(min cm2 bar)
WEP: 1.8 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 4,000 Pads
adhesiveVENTpad
Ø 12.7 / 7.1 mm
0.4 µm PET
Item Number: 090072
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 0.4 µm
Backing: None
Membrane thickness: 36 µm
Filter area: 0.40 cm2
Air flow rate: 7.0 L /(min cm2 bar)
WEP: 1.8 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 3,000 Pads
adhesiveVENTpad
Ø 12.7 / 7.1 mm
1.0 µm PET/PET
Item Number: 090064
Material: Supported Polyester (PET)
Membrane with modified adhesive
Pore size: 1.0 µm
Backing: PET-non-woven
Membrane thickness: 140 µm
Filter area: 0.40 cm2
Air flow rate: 26 L /(min cm2 bar)
WEP: 0.6 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 3,000 Pads
adhesiveVENTpad
Ø 14.0 / 8.0 mm
0.4 µm PET
Item Number: 090069
Material: unsupported Polyester (PET)
Membrane with modified adhesive
Pore size: 0.4 µm
Backing: None
Membrane thickness: 36 µm
Filter area: 0.50 cm2
Air flow rate: 7.0 L /(min cm2 bar)
WEP: 1.8 bar
Surface: hydrophobic & oleophobic
Minimum order quantity: 1,000 Pads
Quantity per roll: 3,000 Pads
All product data given on this website represent typical values.
Product found? Order now >
Your product not yet included? Customization options >
Your contact person
Kevin Eckert
Head of FLUXX
Packaging & Industrial
Application examples
From electronic components in automobiles to housing components for medical technology: TRAKETCH® adhesiveVENTpads from SABEU are self-adhesive membranes that protect sensitive parts and enhance their durability. Our membrane adhesive pads ensure ventilation of components, equalize pressure differences in housings, and prevent the intrusion of unwanted particles, moisture, water, and other liquids. Explore our adhesiveVENTpads here for a variety of different applications.
Life Sciences & Medical
Hydrophobic & oleophobic
| Application | Pore size |
|---|---|
| Sterile Venting of | |
| Suction containers: | 0.2 µm |
| Diagnostic devices: | 0.2 µm |
| Insulin pumps: | 0.2 – 1.0 µm |
| Hospital beds: | 0.2 – 1.0 µm |
| Neurostimulators: | 0.2 – 1.0 µm |
| Sterilization boxes: | 0.2 µm |
| Ostomy bags: | 0.2 µm |
| Transducer protectors: | 0.2 µm |
| Drip chambers: | 0.2 µm |
| Urin bags: | 0.2 µm |
| Cell culture containers: | 0.2 µm |
Hydrophilic
| Application | Pore size |
|---|---|
| Cancer cells (RCC): | 5.0 - 8.0 µm |
| Artificial organs: | 0.08 µm |
| Legionella test: | 0.2 – 0.4 µm |
| Pap test: | 5.0 – 8.0 µm |
| Particle analysis: | 0.2 – 0.8 µm |
| Sterile laboratory filtration: | 0.2 µm |
| Cell and gene therapy: | 0.4 µm |
| Cell culture: Application advisor for Cell Culture Inserts / Plates: | 0.2 – 8.0 µm cellQART® Online Advisor > |
Industrial
Hydrophobic & oleophobic
- Mobile electronics
- Automotive & outdoor electronics
- Lighting technology
- Sensors & measurement technology
- Battery technology & eMobility
- Control technology
- Acoustics & optoelectronics
- Electronic medical technology
Hydrophilic
- Filtration technology
- Environmental analysis
- Measurement analytics
- Air humidification
Packaging
Hydrophobic & oleophobic
- Liquid foods
- Hazardous substances and other chemicals
- Agrochemicals
- Cleaners
- Hygiene and care products
For more information on application possibilities, please click here:
Convenient Installation
SABEU membrane adhesive pads are available in a variety of standard sizes. With our specially developed TRAKETCH® technology, we can customize the membrane adhesive pads to meet customer-specific requirements.
The product advantage: Our self-adhesive membrane pads are made of hydrophobic and oleophobic membranes that ensure airflow while reliably safeguarding from moisture and dirt.
The TRAKETCH® adhesiveVENTpads are practical to use and can be easily applied to components/parts. Thanks to specially modified adhesives, our membrane adhesive pads adhere to a wide range of materials, such as various plastics, aluminum, and steel. The adhesive pads can be applied manually, semi-automatically, or fully automatic. Just peel, stick, and solve!
Product found? Order now >
Your product not yet included? Customization options >
Your contact person
Kevin Eckert
Head of FLUXX
Packaging & Industrial
Customer voice
FAZUA GmbH
Germany
"In our partnership with SABEU, we appreciate their solution-oriented approach of the highly qualified team. They are proactive and consistent with high quality standards, enabling swift and timely realization of our projects and requests.
Video >
Smart Battery Solutions GmbH
Germany
"We are impressed with the proactive and comprehensive consultation, based on a holistic approach ensuring a smooth process and quality products. We are greeted with timely responses and always meet set timelines.“
Let’s collaborate on your next project! Listen here to what our customer Porsche eBike Performance GmbH (FAZUA GmbH) says about SABEU and our adhesiveVENT pads in this video:
Product found? Order now >
Your product not yet included? Customization options >
Your contact person
Kevin Eckert
Head of FLUXX
Packaging & Industrial
Additional membrane configurations
Discover our selection of other standard formats and further product solutions below. You will find an overview of our membrane product variants and your customization options on the overview page of our membrane product portfolio >.
Membrane
Discs
Discs with defined diameters are already designed for immediate processing and assembly.
Membrane
Sheets
Sheets as test samples are ideal for semi-automated and manual production steps.
Membrane
Rolls
Rolls include the opportunity to process our membranes directly in your production process.
All our other membrane product solutions for cell culture and packaging are combined in our own brands separately – click here to continue:
Customized product solutions
Do you require membrane products beyond our standard product portfolio? As the manufacturer of filter membranes and plastic components, we can develop a solution specifically for your requirements.
